- Power/Displacement
- 1.3 HP - 1.0 kW/27 cm³
- Bar length (nose)
- 25 cm, 10'', (microlite sprocket)
- Chain (pitch x gauge)
- 3/8''x.043''
- Adjustement of pruning head
- from 0° to 90° (5 positions)
- Overall length of machine
- 2.60/3.80 m
- Sound pressure/power level
- 97/107.5 dB(A)
- Lh/rh vibration level
- 4.2/5.9 m/s²
- Dry weight without bar and chain
- 7.9 kg
- Complete single item weight including packaging
- 11,9 kg
Data and figures are not binding due to the characteristics of the materials supplied as the products are subject to continuous technical improvements. The data regarding the practical use of the equipment and those of the technical characteristics, as described, may undergo variations without notice.
