- Power/Displacement
- 1.3 HP - 1.0 kW/25.4 cm³
- Bar length (nose)
- 25-30 cm, 10"-12", (sprocket/carving with sprocket)
- Chain (pitch x gauge)
- 1/4” x .043” (carving with sprocket), 3/8" x .050" (sprocket)
- Oil Pump
- aluminium, automatic, zero flow rate at idle speed
- Oil/fuel tank capacity
- 0.19 L/0.22 L
- Sound pressure/power level
- 99/107 dB(A)
- Lh/rh vibration level
- 5.3/5.7 m/s²
- Dry weight without bar and chain
- 3.0 kg
- Complete single item weight including packaging
- 4,9 kg
Data and figures are not binding due to the characteristics of the materials supplied as the products are subject to continuous technical improvements. The data regarding the practical use of the equipment and those of the technical characteristics, as described, may undergo variations without notice.
