- Power/Displacement
- 2.3 HP - 1.7 kW/38.9 cm³
- Bar length (nose)
- 35-41 cm, 14''-16''
- Chain (pitch x gauge)
- Oregon 3/8" x .050"
- Oil Pump
- aluminium, automatic, adjustable, zero flow rate at idle speed
- Oil/fuel tank capacity
- 0.22 L/0.32 L
- Sound pressure/power level
- 103.2/111.5 dB(A)
- Lh/rh vibration level
- 6.9/7.1 m/s²
- Dry weight without bar and chain
- 4.5 kg
- Complete single item weight including packaging
- 6,225 kg
Data and figures are not binding due to the characteristics of the materials supplied as the products are subject to continuous technical improvements. The data regarding the practical use of the equipment and those of the technical characteristics, as described, may undergo variations without notice.
50330124C extra-CE - BIH - HR - F - GB - MNE - RUS - SRB - E - UA50330136 extra-CE - BR50330045 - AR50330125 (E5) - CZ - F - GR - GB - I - NL - PL - P - RUS - SK - E - D50330132 (E5) - TR50330133A (phase II) - CHI50330142 (E5) - H50330143 (E5) - FIN50330144 (E5) - EST - LV - LT50330145 (E5) - SLO50330146 (E5) - BIH - HR - MNE - SRB50330147 (E5) - RO50330148 (E5) - N50330149 (E5) - BG50330150 (E5) - DK
